80ZYT Series

   GENERAL SPECIFICATION

Voltage Range: 12 & 24V dc ( 48V also available )
Power Output Range: 90 ~ 150 W
Speed Range: up to 9,000 rpm
Operational Temperature: -20℃ ~ +40℃
Insulation Class: F ( consult us for class B )
Bear Type: High quality ball bearings
Housing Type: Closed ( ventilated also available )

PERFORMANCE DATA

Part NumberVoltageRated
Power
Rated
Speed
Rated
Torque
Rated
Current
No load
Speed
Length
UnitsVWrpmmNmArpmmm
80ZYT122-12V125412004307.11600122
80ZYT122-24V245412004303.51600122
80ZYT122-40V4054120043021600122
80ZYT135-12V12106290035011.53200135
80ZYT135-24V2410629003505.83200135
80ZYT135-40V40128350035043750135
80ZYT-160-24V246014300.43.51650160
80ZYT-180-24V248810250.825.51300180
80ZYT175-12V122073200620103500175
80ZYT175-24V24201310062063500175
80ZYT175-40V4022133506304.23650175

OUTLINE MAP
